ATEN CS-1794, 4-portový HDMI KVM přepínač pro USB, audio support + 2-portový USB Hub, včetně kabelů
Popis
4-portový HDMI KVM přepínač pro USB, audio support + 2-portový USB Hub, včetně kabelů
Umožňuje plynulé přepínání mezi 4 počítači nebo jinými zařízeními schopnými HDMI, jako např. herních konzol.
With its unique design and innovative features, the CubiQ™ CS1794 USB 2.0 HDMI KVMP™ Switch provides both style and functionality for today's multimedia SOHO environment.
Combining a 4-port switch with a 2-port USB 2.0 hub, the CS1794 provides seamless HDMI signal switching between 4 PCs or other HDMI-enabled devices, such as gaming consoles, and allows users to share USB peripherals from a single console. The CS1794 provides enhanced independent switching via front panel pushbuttons and keyboard hotkeys, and features Video DynaSync™ technology to ensure that HDMI display resolution is always optimized. With integrated digital audio, the CS1794 also allows users to experience high-definition sound, such as Dolby True HD and DTS HD Master Audio.
Ideal for multimedia applications in the home or office, the CubiQ™ CS1794 offers the ultimate in space-saving, streamlined KVM technology for the desktop.
4-port HDMI USB 2.0 KVMP™ Switch
One USB console controls two HDMI-interface computers and two additional USB devices
2-port USB 2.0 hub built in; fully compliant with the USB 2.0 specification
Independent switching of KVM, USB peripheral, and audio focus via front panel pushbuttons and hotkeys
HDMI digital monitor support - fully compliant with HDMI 1.3a; also HDCP compliant
Dolby True HD and DTS HD Master Audio support
Superior video quality - supports 480i, 480p, 720p, 1080i, and 1080p(HDTV)/1920 x 1200(DVI)
Power on detection - If one of the computers is powered off, the CS1794 will automatically switch to the next powered-on computer
Supports widescreen resolutions
Multiplatform support - Windows 2000/XP/Vista, Linux, and Mac
Console mouse port emulation/bypass feature supports most mouse driver and multifunction mice
Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
Complete keyboard emulation for error-free booting
Mac keyboard support and emulation*
* 1. PC keyboard combinations emulate Mac Keyboards
2. Mac keyboards only work with their own computers
Auto Scan Mode for monitoring all computers and HDMI devices
Firmware Upgradable
Package Content
1x CS1794 USB 2.0 HDMI KVMP™ Switch
4x Custom HDMI KVM Cable Sets
1x Firmware Upgrade Cable
1x Power Adapter
1x USB-to-PS/2 Converter
1x User Manual
1x Quick Start Guide
